UHF Fabric Laundry Tags | RFID Linen Label
Produced by RFID, our UHF fabric laundry tags support NXP UCODE 8/9 chips, up to 3 meters read distance, and withstand high temperatures and chemical washing processes.
- Frequency
- 865 – 928 MHz
- Material
- Polyester
- Size
- 35 × 15 mm 55 × 12 mm 56 × 12 mm 70 × 10 mm 70 × 15 mm 75 × 15 mm 88 × 18 mm Customized sizes available
- Minimum order
- On quote
Indicative price$355per unit · final figure confirmed on quotation
Quotations are prepared per format: chip, quantity and encoding format decide the price.
The minimum order shown is a starting point, confirmed on the quote.
Specification
| Product Name | UHF Fabric Laundry Tags / Textile Linen Laundry Tags |
|---|---|
| Available Sizes | 35 × 15 mm 55 × 12 mm 56 × 12 mm 70 × 10 mm 70 × 15 mm 75 × 15 mm 88 × 18 mm Customized sizes available |
| Chip Options | NXP UCODE 8 NXP UCODE 9 |
| Operating Frequency | 865 – 928 MHz |
| Tag Material | Polyester |
| Tag Warranty | First of 200 wash cycles or 3 years from shipment date |
| Read Distance | Up to 3 meters (depends on reader performance and environment testing) |
| Storage Temperature | -40℃ to +120℃ (-40℉ to +248℉) |
| Washing Process Resistance | Washing: +90℃, 60 minutes Drying: +180℃, 3 minutes (35 bar dehydration press) Ironing: +195℃, 30 seconds (<18 bar) Water extraction: 60 bar, 80 seconds Autoclave sterilization: Air removal: +100℃, 5 minutes, 0.1 bar Drying: +45℃, 15 minutes, 0.2 bar Sterilizing: +134℃, 20 minutes, 3.25 bar |
| Chemical Resistance | Resistant to common chemicals used in industrial washing processes |
| Product Documents | Download Product Specification PDF |
| Recommended Products | Need a silicone version? View Silicone Laundry Tags . How to install? See our Tagging Guide for Linens . |
